TowerPro SG92R Mini Servo Motor 180 Degree

TowerPro SG92R Mini Servo Motor (180°)

The TowerPro SG92R Mini Servo Motor is a lightweight and high-performance micro servo designed for precise angular control. It is an improved version of the popular SG90, featuring stronger gears and better torque, making it ideal for robotics, RC models, and embedded systems.

Key Features

• 180° Rotation: Precise position control (~0–180° range)
• High Torque: ~2.5 kg·cm at 4.8V
• Compact & Lightweight: Only ~9 grams
• Improved Gear Design: Carbon fiber/nylon gears for durability
• Fast Response: Quick positioning and smooth motion
• Standard 3-Pin Interface: VCC, GND, Signal (PWM control)

Applications

• Robotics: Arm joints, grippers, and movement control
• RC Models: Aircraft, cars, and boats
• Arduino & ESP Projects: Servo-based automation
• Pan-Tilt Mechanisms: Camera positioning systems
• DIY Electronics: Precise angle control applications

Technical Specifications

• Model: SG92R
• Operating Voltage: 3.0V – 7.2V
• Torque: ~2.5 kg·cm @ 4.8V
• Rotation: ~180° (approx.)
• Speed: ~0.1 sec / 60° (no load @ 4.8V)
• Weight: ~9g
• Control: PWM (Pulse Width Modulation)
• Cable Length: ~20–25 cm

Product Example

TowerPro SG92R Micro Servo Motor (180 Degree)
Compact and reliable servo motor for precise motion control in embedded and robotics applications.

Why Choose SG92R?

The SG92R offers a perfect balance of size, torque, and precision. Compared to basic SG90 servos, it provides better durability and slightly higher torque, making it more reliable for real-world projects.
