The BMP180 Digital Barometric Pressure Sensor Module is a high-precision digital barometric pressure and temperature sensor.
₹49.00 (Excl GST)
| Quantity | Discount | Discounted price |
| 10 - 29 | 2.5% | ₹47.78 |
| 30 - 69 | 5% | ₹46.55 |
| 70 - 100 | 7.5% | ₹45.33 |
The BMP180 Digital Barometric Pressure Sensor Module is a high-precision digital barometric pressure and temperature sensor. It can measure absolute pressure and calculate altitude, making it ideal for weather stations, navigation systems, and altitude tracking applications.
| Parameter | Specification |
|---|---|
| Model | BMP180 |
| Pressure Range | 300 – 1100 hPa |
| Pressure Resolution | 0.02 hPa |
| Pressure Absolute Accuracy | ±1.0 hPa |
| Temperature Range | -40°C to +85°C |
| Temperature Accuracy | ±1.0°C |
| Interface | I2C (up to 3.4MHz) |
| I2C Address | 0x77 (default) |
| Operating Voltage | 1.8V – 3.6V (5V tolerant module) |
| Power Consumption | 3μA standby, 5μA standard mode |
