7x7x14 Tactile push switch (latching)

The 7x7x14 Tactile push switch (latching) is a 7x7x14mm tactile push button switch with latching (stays on until pressed again) operation. Essential for reset circuits, control panels, and manual triggering in electronic projects.

Key Features

• 7x7x14mm package
• latching (stays on until pressed again) operation
• Tactile feedback with audible click
• Through-hole mounting
• Low contact resistance
• Long mechanical life
• SPST configuration

Technical Specifications

Applications

• Reset circuits
• User input interfaces
• Control panels
• Menu navigation
• Manual triggering
• Power switches

Important Notes

• Use internal pull-up or external pull-up resistor
• Debounce in software (10-50ms delay after detection)
• Verify pin spacing matches your PCB/breadboard
• Latching type toggles state on each press
• Momentary type is active only while held down
